项目型号 | PLG200 | PLG300 | PLG500 | PLG1000 | PLG2000 | PLG3000 | PLG4000 | PLG5000 |
罐内工作压力working pressure in tank Mpa | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 |
罐内工作温度 Working temperature in tank ℃ | 133 | 133 | 133 | 133 | 133 | 133 | 133 | 133 |
夹套工作压力 Working pressure in jacket Mpa | 0.25 | 0.25 | 0.25 | 0.25 | 0.25 | 0.25 | 0.25 | 0.25 |
夹套工作温度 Working temperature in jacket | 138 | 138 | 138 | 138 | 138 | 138 | 138 | 138 |
设备容积 Equipment capacity m2 | 0.2 | 0.3 | 0.5 | 1.0 | 2.0 | 3.0 | 4.0 | 5.0 |
加热面积 Heating area m2 | 1.08 | 2.1 | 2.5 | 3.8 | 4.0 | 8.2 | 10.5 | 14 |
电机功率 Motor capacity kw | 0.55 | .055 | 0.75 | 1.5 | 2.2 | 4 | 5.5 | 7.5 |
搅拌转速 Rotation speed for string r/min | 85 | 85 | 85 | 85 | 85 | 85 | 85 | 85 |
容量类别 Capacity type | 一类 |
