型号、项目 | ф100 | 150 | 200 | 300 | 400 |
过滤压力 Filter pressure Mpa | 0.05~0.1 | 0.05~0.1 | 0.05~0.1 | 0.05~0.1 | 0.05~0.1 |
过滤介质微孔滤膜 Filter medium,millipore filter membrane μm | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
水流量 Water flow tons/hour 吨/时 | 0.5~1.0 | 1.5~2.0 | 2.5 | 5 | 10~12 |
层数 Number of layers | 10 | 10 | 10 | 10 | 10 |
型号规格、项目 |
配装滤机长度 Length of filter |
理论滤量(t3/h) Theoretical fitlering capacity |
进出口径(mm) Diameter of inlet and outlet |
过滤孔径(μm) Filtering aperture |
外形安装尺寸宽×长 Installation dimensions wxw |
|
WTL-1×10'' | 10'' | 1 | 0.3~0.5 | 25 | 0.1-10 | 200×600 |
WTL-1×20'' | 20'' | 1 | 0.5~1.0 | 25 | 0.1-10 | 200×850 |
WTL-3×10'' | 10'' | 3 | 1.0~1.5 | 38 | 0.1-10 | 300×850 |
WTL-3×20'' | 20'' | 3 | 1.5~3.0 | 38 | 0.1-10 | 300×1100 |
WTL-5×10'' | 10'' | 5 | 1.5~2.5 | 40 | 0.1-10 | 400×850 |
WTL-5×20'' | 20'' | 5 | 3~5 | 40 | 0.1-10 | 400×1100 |
WTL-7×10'' | 20'' | 7 | 5~7 | 50 | 0.1-10 | 420×1200 |
WTL-7×20'' | 30'' | 7 | 6-10 | 50 | 0.1-10 | 420×1450 |
